GAINTA Sealed Die-Cast Polycarb / ABS

POLYCARBONATE MATERIAL
MOLDED IN LIGHT GRAY

OPERATING TEMPERATURE : -40 DEGREE C TO 120 DEGREE C
  • THE LID AND THE BASE WITH MOUNTING FLANGE INCORPORATE A TONGUE AND GROOVE SEALING SYSTEM WITH A NEOPRENE GASKET
  • THE FLANGED WALL MOUNTING HOLES ARE DESIGNED FOR M3 PAN HEAD MACHINE SCREW USE ( G200MF ) //   M4 PAN HEAD MACHINE SCREW USE ( OTHER ITEMS ).
  • THE BOSSES INSIDE OF THE BASES ARE DESIGNED FOR M3 SELF-TAPPING SCREW USE .
  • BOXES ARE DESIGNED TO IP65 OF IEC 529 AND NEMA 4 ( DUST AND HOSEPROOF )
  • INTERNAL GUIDE SLOTS FOR MOUNTING PCB ASSEMBLIES VERTICALLY


Model No. External Dimension ( mm )
G201MF 64X58X35
G203MF 115X65X40
G205MF 115X65X55
G212MF 115X90X55
G221MF 115X90X80
G214MF 171X121X55
G223MF 171X121X80
G218MF 222X146X55
G232MF 222X146X75
G200MF 90X35X35
